As the 'currency' of science, our publications enable a global impact for health and wellness.

  • Alzouhayli K, Schilaty ND, Wei Y, Hooke AW, Sellon JL, Bates NA. Shear wave elastography demonstrates different material properties between the medial collateral ligament and anterolateral ligament.. Clinical biomechanics (Bristol, Avon). 2024;111:106155. PMID: 38043170

    BACKGROUND: Anterolateral ligament and medial collateral ligament injuries could happen concomitantly with anterior cruciate ligament ruptures. The anterolateral ligament is injured more often than the medial collateral ligament during concomitant anterior cruciate ligament ruptures although it offers less restraint to knee movement. Comparing the material properties of the medial collateral ligament and anterolateral ligament helps improve our understanding of their structure-function relationship and injury risk before the onset of injury.

    METHODS: Eight cadaveric lower extremity specimens were prepared and mechanically tested to failure in a laboratory setting using a hydraulic platform. Measurements of surface strains of superficial surface of each medial collateral ligament and anterolateral ligament specimen were found using three-dimensional digital image correlation. Ligament stiffness was found using ultrasound shear-wave elastography. t-tests were used to assess for significant differences in strain, stress, Young's modulus, and stiffness in the two ligaments.

    FINDINGS: The medial collateral ligament exhibited greater ultimate failure strain along its longitudinal axis (p = 0.03) and Young's modulus (p < 0.0018) than the anterolateral ligament. Conversely, the anterolateral ligament exhibited greater ultimate failure stress than the medial collateral ligament (p < 0.0001). Medial collateral ligament failure occurred mostly in the proximal aspect of the ligament, while most anterolateral ligament failure occurred in the distal or midsubstance aspect (P = 0.04).

    INTERPRETATION: Despite both being ligamentous structures, the medial collateral ligament and anterolateral ligament exhibited separate material properties during ultimate failure testing. The weaker material properties of the anterolateral ligament likely contribute to higher rates of concomitant injury with anterior cruciate ligament ruptures.

  • Weiniger SP, Schilaty ND. Interoceptive posture awareness and accuracy: a novel photographic strategy towards making posture actionable.. Frontiers in neuroscience. 2024;18:1359594. PMID: 38638696

    Interoception, sometimes referred to as the 'hidden sense,' communicates the state of internal conditions for autonomic energy regulation and is important for human motor control as well as self-awareness. The insula, the cortex of interoception, integrates internal senses such as hunger, thirst and emotions. With input from the cerebellum and proprioceptive inputs, it creates a vast sensorimotor network essential for static posture and dynamic movement. With humans being bipedal to allow for improved mobility and energy utilization, greater neuromotor control is required to effectively stabilize and control the four postural zones of mass (i.e., head, torso, pelvis, and lower extremities) over the base of support. In a dynamic state, this neuromotor control that maintains verticality is critical, challenging energy management for somatic motor control as well as visceral and autonomic functions. In this perspective article, the authors promote a simple series of posture photographs to allow one to integrate more accurate alignment of their postural zones of mass with respect to the gravity line by correlating cortical interoception with cognitive feedback. Doing this focuses one on their body perception in space compared to the objective images. Strengthening interoceptive postural awareness can shift the net result of each zone of postural mass during day-to-day movement towards stronger posture biomechanics and can serve as an individualized strategy to optimize function, longevity, and rehabilitation.

  • McPherson AL, Schilaty ND, Anderson S, Nagai T, Bates NA. Arthrogenic muscle inhibition after anterior cruciate ligament injury: Injured and uninjured limb recovery over time.. Frontiers in sports and active living. 2023;5:1143376. PMID: 37025459

    INTRODUCTION: It is well documented that marked weakness of the quadriceps is present after knee joint injury. This joint trauma induces a presynaptic reflex inhibition of musculature surrounding the joint, termed arthrogenic muscle inhibition (AMI). The extent to which anterior cruciate ligament (ACL) injury affects thigh musculature motor unit activity, which may affect restoration of thigh muscle strength after injury, is undetermined.

    METHODS: A randomized protocol of knee flexion and extension isometric contractions (10%-50% maximal voluntary isometric contraction) were performed for each leg on 54 subjects with electromyography array electrodes placed on the vastus medialis, vastus lateralis, semitendinosus, and biceps femoris. Longitudinal assessments for motor unit recruitment and average firing rate were acquired at 6-month intervals for 1 year post ACL injury.

    RESULTS: The ACL-injured population demonstrated smaller quadriceps and hamstrings motor unit size (assessed via motor unit action potential peak-to-peak amplitude) and altered firing rate activity in both injured and uninjured limbs compared to healthy controls. Motor unit activity remained altered compared to healthy controls at 12 months post ACL reconstruction (ACLR).

    DISCUSSION: Motor unit activity was altered after ACLR up to 12 months post-surgery. Further research is warranted to optimize rehabilitation interventions that adequately address altered motor unit activity and improve safety and success with return to sport after ACLR. In the interim, evidence based clinical reasoning with a focus on development of muscular strength and power capacity should be the impetus behind rehabilitation programming to address motor control deficits.

  • Bates NA, Huffman A, Goodyear E, Nagai T, Rigamonti L, Breuer L, Holmes BD, Schilaty ND. Physical clinical care and artificial-intelligence-guided core resistance training improve endurance and patient-reported outcomes in subjects with lower back pain.. Clinical biomechanics (Bristol, Avon). 2023;103:105902. PMID: 36805199

    BACKGROUND: Low back pain is an extremely prevalent issue with an extensive impact, ranging from decreased quality of life to lost years of productivity. Many interventions have been developed to alleviate chronic lower back pain, yet it remains a widespread problem. The objective of this study was to examine the role of artificial intelligence guided resistance training relative to clinical variables in subjects experiencing lower back pain.

    METHODS: 69 out of 108 enrolled and 92 accrued subjects completed the 8-week intervention. Subjects were randomized into four groups (Control, Training, Clinical, or Combined). The Training cohort received supervised artificial-intelligence-guided core-focused resistance training while the Clinical group received clinical care. The Combined group received both clinical care and artificial-intelligence-guided training and the Control group received no treatment. Participants were evaluated using functional testing and patient-reported outcomes at baseline, 4 weeks, and 8 weeks.

    FINDINGS: In the clinical tests, the Clinical and Combined cohorts showed increased total time for isometric extensor endurance and the Clinical cohort increased total distance traveled in the 6-min walk test at 8 weeks. The Training, Clinical, and Combined groups showed improvements in Patient-reported outcomes after 8 weeks. Most of the significant improvements were only seen at the 8-week evaluation for both the clinical evaluations and Patient-reported outcomes. The Control group did not show significant improvements in any outcome measures.

    INTERPRETATION: The present data indicate that core-focused interventions, including artificial-intelligence-guided moderate-resistance exercise, can increase objective functional outcomes and patient satisfaction using Patient-reported outcomes in individuals with lower back pain.

  • Chaney GK, Krause DA, Hollman JH, Anderson VA, Heider SE, Thomez S, Vaughn SN, Schilaty ND. Recurrence quantification analysis of isokinetic strength tests: A comparison of the anterior cruciate ligament reconstructed and the uninjured limb.. Clinical biomechanics (Bristol, Avon). 2023;104:105929. PMID: 36893524

    BACKGROUND: Despite widespread use of return to sport testing following anterior cruciate ligament reconstruction, studies suggest inadequacy in current testing criteria, such as limb symmetry index calculations, to determine athletes' readiness to return to play. Recurrence quantification analysis, an emerging non-linear data analysis tool, may reveal subtle neuromuscular differences between the injured and uninjured limb that are not captured by traditional testing. We hypothesized that isokinetic torque curve data of the injured limb would demonstrate lower determinism and entropy as compared to the uninjured limb.

    METHODS: 102 patients (44 M, 58F, 10 ± 1 months post-anterior cruciate ligament reconstruction) underwent isokinetic quadriceps strength testing using a HumacNorm dynamometer. Patients completed maximum effort knee extension and flexion at 60°/sec. Data were post-processed with a MATLAB CRQA Graphical User Interface and determinism and entropy values were extracted. Paired-sample t-tests (α = 0.05) were used to compare data from the injured and uninjured limb.

    FINDINGS: Determinism and entropy values in the torque curves were lower in the injured limb than the uninjured limb (p < 0.001). Our findings indicate there is less predictability and complexity present in the torque signals of injured limbs.

    INTERPRETATION: Recurrence quantification analysis can be used to assess neuromuscular differences between limbs in patients who have undergone anterior cruciate ligament reconstruction. Our findings offer further evidence that there are changes to the neuromuscular system which persist following reconstruction. Further investigation is needed to establish thresholds of determinism and entropy values needed for safe return to sport and to evaluate the utility of recurrence quantification analysis as a return to sport criterion.

  • Schilaty ND, McPherson AL, Nagai T, Bates NA. Arthrogenic muscle inhibition manifests in thigh musculature motor unit characteristics after anterior cruciate ligament injury.. European journal of sport science. 2023;23(5):840–850. PMID: 35306977

    Joint trauma induces a presynaptic reflex inhibition termed arthrogenic muscle inhibition (AMI) that prevents complete activation of muscles. Reduced motor unit (MU) output is a hypothesised mechanism for persistent strength deficits. The objective of this study was to determine MU characteristics of thigh musculature and determine how they change with anterior cruciate ligament (ACL) injury compared to healthy controls. A randomised protocol of knee flexion/extension isometric contractions (10-50% maximal voluntary isometric contraction) was performed for each leg with surface EMG 5-pin array electrodes placed on the vastus medialis, vastus lateralis, semitendinosus and biceps femoris. Longitudinal assessments for average rate coding, recruitment thresholds and MU action potentials were acquired at 6-month intervals. With exception of the vastus medialis, all thigh musculature of ACL-injured demonstrated smaller MU action potential peak-to-peak amplitude. For average rate coding, ACL-injured demonstrated lower coding rates than Controls for the quadriceps (p < .05) and higher rates than Controls for the hamstrings (p < .05). These MU characteristics were different from Controls after ACL reconstruction up to 12 months post-surgery, yet maximal strength increased during this time frame. As thigh MU characteristics are known across phases of ACL rehabilitation, future studies can assess these patterns of motor control and their potential to determine risk of re-injury. Further, future rehabilitation can target specific intervention programmes to restore motor control.HighlightsMotor unit strategies of arthrogenic muscle inhibition are characterised for the first time via decomposed EMG.Motor unit deficits of thigh musculature persist throughout all phases of ACL rehabilitation, even after return-to-sport.After ACL injury, motor unit sizes at similar recruitment thresholds were smaller than those of healthy controls.
